What “radiant heating design” actually means

People use “radiant heating” to cover three different things – the product, the install, and the design – and the design is the one that decides whether you love your floor or fight it. Design is the engineering: calculating exactly how much heat each room needs, laying out the tubing loops to deliver it, setting the water temperatures and zoning, sizing the heat source, and producing the stamped drawings your permit requires. The install is the easy part once the design is right; the design is where a system is won or lost. Get the design wrong and no installer can save you from lukewarm floors and short-cycling. Get it right and radiant disappears into the background and just works. The day-to-day comfort behind all of it is on radiant floor heating 101, and the heat-source side on hydronic heating.

What a proper hydronic radiant design includes

A complete radiant and hydronic design is a package, not a single number. Here’s what’s in a real one:

PieceWhat it does
Heat-loss / gain (CSA F280-12)The room-by-room heating and cooling load – the foundation everything else is sized from
Loop layout & spacingWhere the tubing runs and how tightly, so each room gets the BTU it needs within the floor’s limit
Supply temperatures & mixingThe low water temperatures and outdoor-reset strategy that make it efficient and even
Zoning & manifoldsHow the home is split into zones for comfort without short-cycling
Heat-source sizingThe right size of combi, boiler, or heat pump – sized to the load, not guessed
Ventilation (MVDS / HRV)The HRV/ERV design a new Ontario home requires, since radiant doesn’t ventilate
Stamped mechanical drawingsThe BCIN-stamped, permit-ready documents your municipality needs

The full breakdown of which of these the code requires, and what the package costs, is on do I need a heat-loss calculation.

Why a stamped design saves you money

A real design does three things for your wallet and your comfort. It right-sizes the equipment, so you’re not paying for an oversized boiler that short-cycles and wastes fuel. It prevents the classic radiant complaints – lukewarm floors, a room that never keeps up – by checking each room’s load against what its floor can supply. And it’s the permit paperwork itself, BCIN-stamped, so your build doesn’t stall at the building department. The calculation costs a few hundred dollars and routinely saves thousands in oversized gear and avoided comfort fixes – which is why we always start here, before anyone picks equipment.

The order that works: heat-loss numbers first, then the design, then the heat source, then the install. We’ve built radiant into our own ICF homes for 30+ years, and the homes that are quiet, even, and cheap to heat are always the ones designed in that order. The leakier the house, the harder the design has to work; in a tight, well-insulated home (especially ICF) the design is easy and the equipment is small. Design and envelope go together.

Hydronic radiant design, specifically

Most whole-home radiant in Ontario is hydronic – warm water, not electricity – and good hydronic design leans on one fact: radiant runs at low water temperatures. That’s what lets it pair efficiently with a condensing boiler, an on-demand combi, or an air-to-water heat pump, and it’s the core of a good design. On most of our jobs we design around a combi on-demand unit running two loops (one potable, one radiant) so you never run out of shower hot water, or an air-to-water heat pump that can also cool the floor in summer. The heat-source options are on hydronic heating, and whether radiant can carry your whole house comes out of the same design, covered on will radiant heat my house.

Upload your plans, get a price – BCIN-stamped, permit-ready.

Get your radiant heating design

Send us your plans and our heat-loss engineer emails you a price for the full radiant and hydronic design package – CSA F280-12 heat loss, loop layout, water temperatures, heat-source sizing, ventilation, and stamped mechanical drawings, ready for your permit. This is the work we do, and we can build it too.
